Moisture Balances



Contech Moisture Analyzer incorporates rapid Halogen heating with EMFC precision weighing technology to determine moisture content of samples quickly and effectively.




  Moisture Balances (0.001 g - 220 g)
 Easy & Fast Moisture Determination
 3 types of Testing Methods:- Manual, Time Programmable, Automatic
 Weighing based on EMFC technique
 Halogen lamp heating
 Temperature range upto 2000C (1°C)
 Moisture range: 0.05% to 100%

 Moisture measurement: Unit-
      % wet base
      % dry base dry weight
      % dry to wet weight
 Display of time, temperature, weight & percentage moisture
 Graphical backlight LCD for displaying setup parameters, testing parameters &  results
 Standard bi-directional RS-232 interface
 Data storage upto 50 tests
 10 programmable memory
 Study of Pattern of Moisture loss by printing/Display on computer screen of online  data- elapsed time, present sample weight and moisture loss. Elapsed time interval can be  programmed -10,20,30,60 & 120 Seconds



  Specifications

  MODELS   CB 50 (M)  CA-123 (M)    CA-223(M)
  CAPACITY  50g  120g  220g
  READABILITY  0.001g  0.001g  0.001g
  Pan Size  100 mm  100 mm  100 mm


 Moisture Content:

  • Accuracy: 0.05% for sample above 5g
  • 0.1% for sample below 5g
  • Resolution: 0.1%

 Specifications

   Taring Range : Up to full capacity
   Response time : 4 to 6 secs
   Display : Backlite LCD
   Power Req : 90-250V, 50/60Hz, 550 Watt
   Operating Temperature : 10 to 45 deg C
